Harris Gas Regulator – 3000 psi – 15 psi – CGA-580 – Argon – Helium – Nitrogen | 3302606
Regulators & Flowmeters

Harris Gas Regulator – 3000 psi – 15 psi – CGA-580 – Argon – Helium – Nitrogen | 3302606

Original price was: $577.00.Current price is: $105.98.

Availability: 8 in stock

🚚 Free Shipping over $38
✓ Premium Quality
🔒 Secure Payments
↻ Money Back Guarantee
SKU: har3302606
CATEGORY: Regulators & Flowmeters
Description

Harris Gas Regulator – 3000 psi – 15 psi – CGA-580 – Argon – Helium – Nitrogen

Features

  • General purpose applications where neoprene diaphragms are acceptable
  • Designed for applications where a constant delivery pressure is required
  • Easy-to-operate brass T screw adjusting handle
  • 2 in Steel dual scale easy-to-read gauges
  • One-piece encapsulated seat design with internal filter to protect the PTFE Teflon seat from particulate contamination
  • Equipped with a tamper-proof, self-reseating, high pressure internal safety relief valve
  • Conforms to CGA E-4 standard

    • Specifications

    Brand Harris Products
    Body Material Brass
    Gas Service Argon, Helium, Nitrogen
    Inlet Connection CGA-580
    Maximum Inlet Pressure 3000 psi
    Maximum Outlet Pressure 30 psi
    Minimum Outlet Pressure 15 psi
    Number of Stages Two
    Outlet Connection 5/8-18 RH(F)
    Product Type Gas Regulator
    Diaphragm Material Neoprene
    MFG 3302606
