Thermal Dynamics Cutmaster 30+, 120-240V 1PH #1-3000-1

Thermal Dynamics Cutmaster 30+ Package, 120 – 240 V 1 ph (NEMA 6-50 plug, 115 V adapters) CSA #1-3000-1

Cutmaster 30+ is the perfect combination of power and portability for hand-held plasma cutting machine. Plus means more, so we’ve added a user-friendly 4.3 in. TFT LCD screen and upgraded features that give you even more control and flexibility to master any cut up to 10 mm (3/8 in.). Together with the SL60 1Torch, it all adds up to the total plasma cutting package.

Recommended pierce and cut capacity: 10 mm (3/8 in.) Maximum edge cut capacity: 16 mm (5/8 in.)

• Portable and durable with three handles and lightweight, industrial all-weather housing
• Bright 4.3 in. TFT LCD display with glove-friendly adjustment knob simplifies use and provides greater control and flexibility
• Dual input 110-240 V, 1 ph power with automatic voltage detection that sets max output amperage
• Comes with industrial SL60 1Torch featuring 2T/4T function, safety trigger lock, and double-tap trigger to conserve bottled air
• Switch between normal and grate cutting modes
• Automatic air pressure detection and post-cut air purge to expand consumable life
• 40% duty cycle @ 30 A, 100% @ 20 A
• Cutmaster Black Series consumables included for up to 60% longer life
• Industry leading 3-year warranty on power supply and 1-year warranty on torch and leads

Industries

• Industrial and General Fabrication
• Light Fabrication
• Industrial Production & Manufacturing
• Automotive Bodies
• Hobbyist
• Agricultural Equipment
• HVAC
• Repair and Maintenance
• Pipeline
• Training Schools

Power + Portability.

Tackle cuts in any terrain with industrial housing and a compact design.

• Pierce and cut capacity of 3/8 in. and a maximum edge cut capacity of 5/8 in.

• 40% duty cycle at 30 A and 100% duty cycle at 20 A

• Runs on both 110 and 240 V input with auto-voltage detection

• Lightweight design with three handles for easy transportation

• Durable, weather-protected IP23S housing

Efficiency + Ease.

Mastering cuts is simple with our user-friendly TFT LCD screen.

• Bright 4.3 in. screen is optimal for displaying settings and making adjustments

• Adjustable 2T/4T trigger lock to achieve long cuts by hand or with MechPak

• Automatic air pressure recognition and purging for proper cutting pressure and extended consumable life

• Comes standard with long-lasting Cutmaster Black Series electrodes

Simplicity + Flexibility.

Dominate any plasma cutting job with built-in functionality and flexibility.

• Switch from normal plate to grate cutting mode to extend consumable life when working with expanded metal

• Equipped with SL60TM 1Torch® and a full range of consumables for both shielded and unshielded cutting and gouging

*Cutmaster 30+ power supply SL60 75° torch with lead 3 m (10 ft) work lead with ground clamp consumables kit regional input power plugs per above 1/4 in. NPT air fitting. Cutmaster 30+ is compatible with all 11Torch ATC torch connections.

This product replaces these legacy models:

• Thermal Dynamics Cutmaster 42 Plasma Cutter #1-4200
• Thermal Dynamics Cutmaster 42 Plasma Cutter w/SL60 Torch #1-4200-SL60
