I-Purge XABLD Modular Inflatable Bladder System – 14 – 18 in
The I-Purge X is the most adaptable and technologically advanced modular inflatable bladder system available to date. The I-Purge X comes equipped with its revolutionary Bladder Expansion Technology (BET) that enables one unit to fit multiple pipe sizes. Bladders have the ability to expand and contract to fit each piping specification and are protected by a spark resistant exterior cover that does not combust when exposed to flames and sparks. These state-of-the-art features allow the operator to create multiple configurations, including a one-sided pipe stopper and reducer. Bladders are available in sizes ranging from 2″- 3″ (51 mm – 76 mm) to 38″- 48″ (965 mm – 1219 mm) and may be purchased either individually or as a complete system, a distinct advantage should additional sizes be desired or a component need replacing. Coupled with an extended length, high heat resistant harness; the I-Purge X is the most versatile pipe purging solution available and is ideal for fabrication shops and any environment with pipe accessibility. Manufactured in the USA from the highest quality materials, the I-Purge X is a reusable, long-term solution that is expandable, extendable, and simply extraordinary.
Features
Equipped with proprietary Bladder Expansion Technology (BET) that enables one unit to fit multiple pipe sizes and schedules
Designed to expand and contract numerous times
Manufactured in the USA from the highest quality materials
Inflated bladders create an impermeable, air tight seal on pipe wall for multiple inflation dimensions
Spark resistant, durable exterior cover does not melt
Heavy-duty interior inflatable bag
Re-usable, long-term solution for purging multiple pipes of the same diameter
Internal hose and protective external fiberglass sleeve capable of withstanding high temperatures
Flexible bridge harness easily navigates through pipes, including elbows and tees over 90°
Kink resistant hose assures continuous gas supply
Complete with luminescent indicator for accurate alignment at root gap
Various lengths of harnesses available to accommodate heat affected zone (HAZ) during pre-heating and high heat applications
I-Purge X 38″ to 48″ is equipped with a high flow harness to expedite inflation
Push-button feature enables modules to snap-in-place in seconds
State-of-the-art technology allows for greater versatility and easy assembly – enabling the user to create multiple configurations
Easy change and replacement of components to avoid costly re-purchase of complete system, with spare parts available for separate purchase
Corrosion resistant proven lock mechanism for secure connection
Patent-pending technology
Reduces turbulence by dispersing inert gas equally in all directions within the weld zone, improving weld quality and consistency
