EATON CONNECTOR – 2-3/0 AWG | 627-A201317-1
Wire & Cable Tools

EATON CONNECTOR – 2-3/0 AWG | 627-A201317-1

Original price was: $58.03.Current price is: $17.41.

Availability: 9 in stock

🚚 Free Shipping over $38
✓ Premium Quality
🔒 Secure Payments
↻ Money Back Guarantee
SKU: cala201317-1
CATEGORY: Wire & Cable Tools
Description

EATON CONNECTOR – 2-3/0 AWG

Eaton Crouse-Hinds series Cam-Lok F Series E1012 terminal connector, Up to 315A continuous, 550A intermittent, #2-3/0 AWG, Red, Female, Thermoplastic elastomer (TPE) or reinforced thermoplastic, 1/2″ bolt hole, Angle, 120 Vac

Features

  • Double cam principle provides a positive, vibration-proof connection.
  • Self-compensating for wear.
  • No moving contact surfaces, eliminating arcing or burning.
  • Superior electromechanical connections.
  • Locked contacts will withstand a pulling force of 1,000 lbs.
  • 1/3 of a turn assures a high pressure contact approaching 600 lbs. per sq. in. providing minimum resistance.
  • Contacts carefully machined from a high conductivity brass to a smooth sliding fit and easy locking action.
  • Product body molded from colorfast material, color-coded for easy identification.
  • Panel receptacles are safety insulated for direct mounting to steel panels.
  • Accepts a wide range of cable sizes.

    • Specifications

    Brand Cam-Lok
    Hole Size 1/2 in
    Amperage 315 A, 550 A
    Cable Gauge 2-3/0 AWG
    Color Red
    Connection Type Female
    Overall Length 3.63 in
    Overall Width 1.5 in
    Product Type Connector
    Voltage 120 VAC
    MFG 627-A201317-1
